T ESTING AND T ROUBLESHOOTING : T EST S OFTWARE
0 2. 3 0 0 4. 0 3 00 . 5 4 107
4
7 Cycle from index 0 to index 3 CW, and
from index 3 to index 0 CCW repeat-
edly. Pause briefly on index 0 and 3.
(Test Type 9E)
6 Cycle from index 0 to index 6 CCW,
and from index 6 to index 0 CW repeat-
edly. Pause briefly on index 0 and 6.
(Test Type 8C)
5 Continuously index CW to next gobo
position on wheel (from 2 to 3, form 5 to
0). Gobos on wheel do not rotate.
Pause briefly on each gobo. (Test Type
9C)
4 Cycle gobos between orientation 0
degrees & 180 degrees repeatedly.
Wheel does not move. Pause briefly at
0 and 180 degrees. (Test Type 9B)
3 Type 9A CCW, 100% speed
2 Type 9A CCW, 50% speed
1 Type 9A CCW, 25% speed
0 Spin gobos CW at 100% speed, wheel
does not move.
(Test Type 9A)
010 Strobe 9 65% speed strobe to EOT stop,
(closed)
8 65% speed strobe to middle position
between EOT stops. (open)
7 25% strobe from open stop to closed
stop repeatedly (i.e. cycling)
6 35% strobe cycling
5 45% strobe cycling
4 55% strobe cycling
3 65% strobe cycling
2 75% strobe cycling
1 85% strobe cycling
0 Full speed (100%) strobe cycling
013 All Async All tests above will run asynchronously.
All motors will reach respective EOT
stops (if applicable) and begin motion
to opposite EOT stops at each motor’s
earliest opportunity. Motion will not be
coordinated between motors.
021 Sensors 9 Monitor Lens 3 Sensor
8 Monitor Lens 2 Sensor
7 Monitor Lens 1 Sensor
6 Monitor Strobe Sensor
5 Monitor Fixed Gobo Sensor
Table 4-7: VL7/VL7U Mechanical Tests (Continued)
Test Number Test Parameter Error Codes/Comments
