T ESTING AND T ROUBLESHOOTING : T EST S OFTWARE
0 2. 3 0 0 4. 0 3 00 . 5 4 101
4
0 Speed 5 Spin
(Full Speed)
Spin Speeds match those
available from console
012 All Motors
(synchronized)
013 All Motors
(unsynchronized)
912 End Motor
(in cal. position)
Table 4-4: VL6 Spot Luminaire Default Programs
Test Number Test Functions
31 Pan and Tilt 701 Pan 25% Speed
702 Tilt 25% Speed
39 VL6 Functions 703 Beam 25% Speed
705 Edge 25% Speed
706 Wheel 1
Continuous Frame
707 Wheel 2
Continuous Frame
Table 4-5: VL6B/VL6C/VL6C+ Spot Luminaire Mechanical Tests
Test Number Test Parameter Error Codes/Comments
000 Start Test 9 End Stop (OPEN) 103 No Reset (PAN)
001 Pan Test 8 End Stop (CLOSED) 203 No Reset (TILT)
002 Tilt Test 7 Speed 1 104 No Reset (PAN)
003 Beam Test 6 Speed 2 204 No Reset (TILT)
5 Speed 3 (45%)
4 Speed 4 (55%)
3 Speed 5 (65%)
2 Speed 6 (75%)
1 Speed 7 (85%)
0 Speed 8 (FULL SPEED)
004 Lens Test 7 All move to front EOT, Lens
1 cycles full travel (100%)
6 Lens 1 move to rear EOT,
Lens 3 move to from EOT,
Lens 2 cycles full travel
(33%)
Table 4-3: VL6 Spot Luminaire Mechanical Tests (Continued)
Test Number Test Parameter Error Codes/Comments
