DMX512 R EFERENCE G UIDE
1 0 2 02.3004.0300.54
5 Lens 1 move to rear EOT,
Lens 3 move to front EOT,
Lens 2 cycles full travel
(66%)
4 Lens 1 move to rear EOT,
Lens 3 move to front EOT,
Lens 2 cycles full travel
(100%)
3 All lenses move to rear EOT,
Lens 3 cycles full travel
(33%)
2 All lenses move to rear EOT,
Lens 3 cycles full travel
(66%)
0 All synchronous (100%)
005 Intensity Test 9 End Stop (OPEN) 511 Hit Sensor When Not
Expecting To
8 End Stop (CLOSED) 514 Did Not Hit Sensor
When Expecting To
7 Speed 1
6 Speed 2
5 Speed 3
4 Speed 4
3 Speed 5
2 Speed 6
1 Speed 7
0 Speed 8 (FULL SPEED)
006 Wheel 1 Test 9 CW 1 Frame To Sensor 611 Hit Sensor When Not
Expecting To
007 Wheel 2 Test 8 CCW 1 Frame To Sensor 614 Did Not Hit Sensor
When Expecting To
7 CW 1 Frame To Sensor
(Osculating)
711 Hit Sensor When Not
Expecting To
6 CCW 1 Frame To Sensor
(Osculating)
714 Did Not Hit Sensor
When Expecting To
5 Continuous Frame Step Direction Opposite of
Spin
4 Speed 1 Spin
3 Speed 2 Spin
2 Speed 3 Spin
1 Speed 4 Spin
0 Speed 5 Spin (Full Speed) Spin Speeds match
those available from
Console
009 Rotating Gobos 9 Wheel position is open (no
gobo)
Table 4-5: VL6B/VL6C/VL6C+ Spot Luminaire Mechanical Tests (Continued)
Test Number Test Parameter Error Codes/Comments
