Technical Data
UNIVERSAL SYNC INPUTS
Interfaces
2 x BNC female, unbalanced, isolated from earth, 200mV-5.0V,
input impedance 75Ω (switchable)
Synchronizable references HD tri-level sync
SD bi-level sync
(PAL/SECAM + NTSC )
Word Clock, every audio clock rate from 8.0kHz to 24.576MHz,
incl. Word Clock x 256 for ProTools
™ systems
DSD64, DSD128 + DXD
AES3, AES11, AES3id, AES11id, every audio clock rate from 32.0kHz to 192.0kHz
S/P-DIF, every audio clock rate from 32.0kHz to 192.0kHz
GPS / atomic clock, 1.0MHz, 2.5MHz, 5.0MHz, 10.0MHz
Telecom, 1.024 MHz, 2.048MHz
DCF77, 77.5kHz
MFS60, 60.0kHz
AES/EBU SYNC INPUT
Interface
1 x XLR female, transformer balanced, input impedance 110Ω, 200 mV-7.0 V
Formats AES3-1992/2003 + AES11-1997/2003
Resolution 16 – 24bits
Lock range Every audio clock rate from 32.0kHz to 192.0kHz
VIDEO SYNC OUTPUTS
Interface
4 x BNC female, unbalanced, output impedance 75Ω, individually buffered,
adjustable in pairs
Output levels 300 mV (p-p) burst level @ 75 Ω
300 mV (p-p) H/V sync level @ 75Ω
2.0 V (p-p) H/V sync level @ 75Ω, only composite sync
Video sync formats PAL or NTSC Black + Burst or composite sync
WORD CLOCK SYNC OUTPUTS
Interface
8 x BNC female, unbalanced, individually buffered, adjustable in pairs
Output levels 2.5 V (p-p) @ 75Ω, output impedance 75Ω
3.5 V (p-p) @ 75Ω, output impedance 22Ω
Generatable clock rates 36 audio clock rates, 2 DSD clock rates, 6 pilot tone clock rates, 4 GPS / atomic clock rates,
1 audio player basic clock rate
AES/EBU SYNC OUTPUTS
Interface
4 x XLR male, transformer balanced, 4.0V (p-p) @ 110Ω, output impedance 110Ω,
individually buffered, adjustable in pairs
Format AES11-1997/2003 in generator mode; AES3-1992/2003 + AES11-1997/2003 in distribution mode
Format adjustments Professional/consumer, audio status, reference status, lock status, DC offset - 90dBFs
Resolution adjustments 16bits, 18bits, 20bits or 24bits
Generatable clock rates Every audio clock rate from 16.0kHz to 192.0kHz
S/P-DIF SYNC OUTPUTS
Interface
2 x Coaxial (Cinch/RCA female), unbalanced, 0.5V (p-p) @ 75Ω, output impedance 75Ω,
individually buffered, adjustable in pairs
Format IEC 60958 blank frame
Format adjustments Consumer/professional, audio status, reference status, DC offset - 90dBFs
Resolution adjustments 16bits, 18bits, 20bits or 24bits
Generatable clock rates Every audio clock rate from 16.0kHz to 192.0kHz
INTERNAL REFERENCE OSCILLATOR SPECIFICATIONS
Oscillator type
TCXO, temprature compensated crystal oscillator, burned-in and pre-aged
Clock accuracy (shipped) < ± 0.1ppm
Clock stability versus
temperature
< ± 0.5ppm
Clock jitter < 10ps (RMS), measure bandwidth: 20.0Hz – 100.0kHz
Operating temperature - 10°C to + 60°C
