This menu page provides information in internal system statuses and
cannot be edited.
TERM IN1 / IN2
TERMINATION - INPUT1 / INPUT2 This informs on the internal termination
status of the two universal clock-source inputs INPUT1 and INPUT2. The
factory default is ON for both inputs.
ON = internal termination enabled
OFF = internal termination disabled
Refer to the »Configuring the Terminations« section in the appendix.
POWER SUPPLY
POWER SUPPLY This informs on the status of the internal power supplies
and shows how many of them are active. The iCLOCK standard version is
shipped with one power supply while the iCLOCK dp version contains two
power supplies to ensure redundant (failsafe) operation.
The factory defaults are:
iCLOCK standard version: 1-ON 2-N.A. (one active power supply)
iCLOCK dp: 1-ON 2-ON (two active power supplies)
OK (setting)
The respective power supply is active.
N.A. (setting)
NOT AVALABLE This message shows that the respective power supply is not
available (only when using the iCLOCK basic version).
LOST (setting)
LOST indicates that a power supply has failed or that the external mains
voltage is not available (iCLOCK dp only).
SOFT
SOFTWARE VERSION This informs on the currently installed operating sys-
tem of your iCLOCK or iCLOCKdp.
V220 (setting)
These letters and numbers represent the currently installed software versi-
on of iCLOCK or iCLOCKdp:
V = Version
220 = 2.20
Failure Messages
If one of the statuses 1-FAIL or
2-FAIL is indicated (iCLOCK dp only),
safe operation is not guaranteed! Contact
the technician in charge immediately!
!
G L O B A L T E R M I N 1 / I N 2 P O W E R S U P P L Y S O F T
4 / 4 O N O N 1 - O K 2 - N . A . V 2 1 1
|
<
|
<
GLOBAL 4 / 4
Functions and settings on the GLOBAL 4/4 menu page:
