7 Address Content Summary
If the color shading is the same, the information in the table cells is the same between narrowband and
wideband measurements. Note that Outlet 1 = channel A and Outlet 2 = channel B.
Table 10: MPU Output Summary Chart
Outlet 1
Address
Narrowband
Address
Wideband
Common Data
00
Delta Temp
20
Delta Temp
01
Line Frequency
21
Line Frequency
02
Alarm Status
22
Alarm Status
03
Over Current Event Count
23
Over Current Event Count
04
Under Voltage Event Count
24
Under Voltage Event Count
05
Over Voltage Event Count
25
Over Voltage Event Count
06
Volts
26
Volts
Common, Outlet 1
Specific Data
07
Watts (A)
27
Watts (A)
08
Energy (A)
28
Energy (A)
09
Cost (A)
29
Cost (A)
Tier 1, Outlet 1 Specific
Data
0A
Current (A)
2A
Current (A)
0B
VAR (A)
2B
VAR (A)
0C
VA (A)
2C
VA (A)
0D
Power Factor (A)
2D
Power Factor (A)
0E
Phase (A)
2E
Phase (A)
0F
(Reserved for Future)
2F
(Reserved for Future)
Tier 2, Outlet 1 Specific
Max/Min Data
10
Vrms Min
30
Vrms Min
11
Vrms Max
31
Vrms Max
12
Watts Min (A)
32
Watts Min (A)
13
Watts Max (A)
33
Watts Max (A)
14
Current Min (A)
34
Current Min (A)
15
Current Max (A)
35
Current Max (A)
16
VAR Min (A)
36
VAR Min (A)
17
VAR Max (A)
37
VAR Max (A)
18
VA Min (A)
38
VA Min (A)
19
VA Max (A)
39
VA Max (A)
1A
Power Factor Min (A)
3A
Power Factor Min (A)
1B
Power Factor Max (A)
3B
Power Factor Max (A)
1C
Phase Min (A)
3C
Phase Min (A)
1D
Phase Max(A)
3D
Phase Max(A)
1E
(Reserved for Future)
3E
(Reserved for Future)
1F
(Reserved for Future)
3F
(Reserved for Future)
