FDD_6612_ 010 6612_OMU_S2_URT_V1_13 Firmware Description Document
Rev. 1.1 45
MPU
Parameter
Location
(hex)
LSB Default Comment Example
Peak I
Total_wb
Alarm
Threshold
E5 mArms +20.000
Maximum Wideband Current
measured on Outlet 1 plus
Outlet 2 above which a flag
must be set (bit 20 of the
Alarm Status Register).
If the wideband peak
current threshold on
Outlet 1 plus Outlet 2 is
to be changed from the
default value of 20 Amps
to 30 Amps then set as
follows:
)E5=+30.000
Alarm
Mask_Reg
E6 – 00801FFF
Alarm mask for bits in the
Alarm Status register. A “0”
masks the bit.
If bits 0 and 1 are to be
masked then set as
follows:
>)E6=FFFFFFFC
Alarm
Mask_DIO
E7 – 00801FFF
Control
Relay
F0 – 0
Bit 1 (Relay for Outlet 2)
0 = DIO19 = 0
1 = DIO19 =1
Bit 0 (Relay for Outlet 1)
0 = DIO7 = 0
1 = DIO7 = 1
Note: AC[1] = 1 inverts the bits
above.
Min/Max
Control
F1 – 0
BIT1 – 1 Start/Stop MIN/MAX
recording.
1 = Start
0 = Stop
BIT0 – 1 Reset MIN/MAX
registers. Bit autoclears. Starts MIN/MAX
recording.
)AC=10
)AC=01
Resets the MIN/MAX
registers.
Clear
Control
F2 – 0
Clear Control Register:
Bit1 – Clears Counts
Bit 0 – Clears Accumulators.
