MPU
Parameter
Location
(hex)
LSB Default Comment Example
Peak IA_wb
Alarm
Threshold
D9 mArms +15.000
Maximum Wideband Current
measured on the IA channel
above which a flag must set
(bit 8 of the Alarm Status
Register).
If the peak wideband
current threshold on
Outlet 1 is to be changed
from the default value of
15 Amps to 30 Amps
then set as follows:
)D9=+30.000
PFA_nb_Neg
Threshold
DA – -0.700
Narrowband Power Factor
Negative Threshold for Outlet
1. A less negative narrowband
power factor than this
threshold will set an alarm (bit
9 of the Alarm Status
Register).
If the negative
narrowband power factor
threshold on Outlet 1 is
to be changed from the
default to -0.6 then set
as follows:
)DA=-0.600
PFA_nb_Pos
Threshold
DB – +0.700
Narrowband Power Factor
Positive Threshold for Outlet 1.
A narrowband power factor
less than this threshold will set
an alarm (bit 10 of the Alarm
Status Register).
If the positive
narrowband power factor
threshold on Outlet 1 is
to be changed from the
default to +0.600 then
set as follows:
)DB=+0.600
PFA_wb_Neg
Threshold
DC – -0.700
Wideband Power Factor
Negative Threshold for Outlet
1. A less negative wideband
power factor than this
threshold will set an alarm (bit
11 of the Alarm Status
Register).
If the negative wideband
power factor threshold
on Outlet 1 is to be
changed from the default
to -0.6 then set as
follows:
)DC=-0.600
PFA_wb_Pos
Threshold
DD – +0.700
Wideband Power Factor
Positive Threshold for Outlet 1.
A positive wideband power
factor less than this threshold
will set an alarm (bit 12 of the
Alarm Status Register).
If the positive wideband
power factor threshold
on Outlet 1 is to be
changed from the default
to +0.6 then set as
follows:
)DD=+0.600
Peak IB_nb
Alarm
Threshold
DE mArms +15.000
Maximum Narrowband Current
measured on the IB channel
above which a flag must set
(bit 13 of the Alarm Status
Register).
If the peak narrowband
current threshold on
Outlet 2 is to be changed
from the default value of
15 Amps to 30 Amps
then set as follows:
)DE=+30.000
