FDD_6612_ 010 6612_OMU_S2_URT_V1_13 Firmware Description Document
Rev. 1.1 35
Output
Location
(hex)
LSB Comment Example
Irms_nb T
Max
8B mArms
Maximum combined outlet
narrowband rms current measured.
If the largest narrowband current
measured on both outlets is 30
Amps
)8B?
Returns:
+30.000
VARs_nb T
Min
8C mW
Minimum combined outlet
narrowband reactive power
measured (per second).
If the largest narrowband VARs
measured on both outlets is 80
VARs
)8C?
Returns:
+80.000
VARs_nb T
Max
8D mW
Maximum combined outlet
narrowband reactive power
measured (per second).
If the largest narrowband VARs
measured on both outlets is 300
VARs
)8D?
Returns:
+300.000
VAs_nb T
Min
8E mW
Minimum combined outlet
narrowband apparent power
measured (per second).
If the smallest narrowband VAs
measured on both outlets is 80
VARs
)8E?
Returns:
+80.000
VAs_nb T
Max
8F mW
Maximum combined outlet
narrowband apparent power
measured (per second).
If the largest narrowband VAs
measured on both outlets is 300
VARs
)8F?
Returns:
+300.000
