FDD_6612_ 010 6612_OMU_S2_URT_V1_13 Firmware Description Document
Rev. 1.1 49
CE
Parameter
Location
(hex)
LSB Default Comment Example
QUANT IB 17
(IMAX B)
2
*
4.6351E-11
(A
2
)
0
IA input
compensation
added for input
noise and
truncation in the
squaring
calculation for I
2
.
Used for
compensation at
low current
levels. Keep
below 10000d.
Reserved 18 – – Reserved Reserved
Gain
Adjust
19
16384 is
the
default
and is a
gain of 1.
+16384
32767 is max
giving a
gain of 2.
To increase all channels equally by
1% scale the nominal number,
16384 by 1/(1-0.01). Number to be
entered would be 16549:
]19=+16549
To decrease all channels 1% scale
the nominal number, 16384 by
1/(1+0.01). Number to be entered
would be 16222:
]19=+16222
Reserved 1A – – Reserved Reserved
Reserved 1B – – Reserved Reserved
