FDD_6612_ 010

6612_OMU_S2_URT_V1_13 Firmware Description Document

Rev. 1.1

29

Output

Location

(hex)

LSB

Comment

Example

Phase

Angle_nb B

Max

5D

–

Outlet 2 maximum narrowband

phase angle measured.

If the maximum narrowband phase

angle measured on Outlet 2 is 70

degrees

)5D?

Returns:

+70.000

Reserved

5E

–

Reserved

Reserved

Reserved

5F

–

Reserved

Reserved
