16/18 Manual
3
Packing List
Description Quantity
Spectrophotometer ............................................................... 1
Mains Lead ........................................................................... 1
Cuvettes................................................................................ Set of 4, glass
.......................................................................... Set of 2, quartz
Manual .................................................................................. 1
Note: the qurtz cuvette will not be included in the visible instruments.
Specifications:
Installation:
1. After carefully unpacking the contents, check the materials with the packing list
(page 2) to ensure that you have received everything in good condition.
2. Place the instrument (Fig.1-3) in a suitable
location away from direct sunlight. In order to have the best performance from
Model
63(&752V16 63(&752V18 63(&752UV16 SPECTRO-UV18
Wavelength Range 320-1100nm 190-1100nm
Spectral Bandwidth 4nm 2nm 4nm 2nm
Optical System Single Beam, Grating 1200lines/mm
Wavelength Accuracy ±0.5nm
Wavelength Repeatability 0.3nm
Wavelength Resolution ±0.1nm
Photometric Accuracy ±0.3%T
Photometric Repeatability ±0.2%T
Photometric Range -0.3-3A, 0-200%T
Stray Light 0.05%T@360nm 0.05%T@220nm,340nm
Stability ±0.002A/h @500nm
Display Graphic LCD (128X64 dots)
Keyboard 22 Membrane keypad
Photometric Mode T, A, E
Detector Si Photodiode
Sample Compartment
Standard 10mm path length cuvette
Accommodates 100mm path length cuvette with optional holder
Light Source Tungsten lamp Tungsten & Deuterium
Output USB Port Parallel Port (printer)
Power Requirement AC 220V/50Hz or 110V/60Hz
Dimensions (W x D x H) 470 x 370 x 180mm
Weight 12kg 14kg
