16/18 Manual
20
interface.
Display Data
Move the cursor on “ Display Data” by pressing 【∧ ∧ ∧ ∧】 and 【∨ ∨ ∨ ∨】 in setting
interface, followed by 【
ENTER
】 .(Fig. 38)
ENTER
RETURN
Fig. 38
5 lines of data be displayed every screen. press 【∧ ∧ ∧ ∧】 and 【∨ ∨ ∨ ∨】 to scroll.
☺ Data Print
Press 【 PRINT
】 in the right interface of Fig.38, the data will be printed.
After printing, the data will be deleted from the screen and RAM.
Press 【
CLEAR
】 can also delete the data.(Fig. 39)
Fig. 39
4. Utility
Move the cursor on “ Utility” by pressing 【∧ ∧ ∧ ∧】 and 【∨ ∨ ∨ ∨】 in main menu, followed
by 【
ENTER
】 .10 items will to be set. (Fig. 40)
ENTER
RETURN
√ √ √ √Utility
● ● ● ●D2 Lamp on/off
○
○ ○ ○W Lamp on/off
○
○ ○ ○Printer
○ ○ ○ ○Basic Mode
○
○ ○ ○Quantitative
○
○ ○ ○Kinetics 15:15
●
● ● ●Utility 04/21
√ Kinetics
○ ○ ○ ○Upper Limit
○
○ ○ ○Lower Limit
●
● ● ●Display Data
No. Abs
1
0.000
2 0.001
3 0.002
4 0.003
Kinetics： ： ： ：
Wavelength: 546.0nm
NO. Abs. T%
1 0.000 100.0%
2 0.000 100.0%
