PXL-500 / PXL-510 Tiger Controller
Quick Start Guide
Page 2 of 24 P/N: 01918-001 Rev. B
1.0 Specifications
Unit Dimensions
•
PXL-500/PXL-510 controller PCB
- 6.75 inches high by 6.00 inches wide by 1.75 inches deep, including wiring connectors
- (17.15 cm by 15.25 cm by 4.45 cm)
• PXL-500/PXL-510 controller PCB with an LCD-1 Alpha/Numeric Display
- 7.70 inches high by 6.00 inches wide by 1.75 inches deep, including wiring connectors
- (19.60 cm by 15.25 cm by 4.45 cm)
• PXL-500/PXL-510 controller PCB with an SB-593 Satellite Board (with or without an LCD-1 Alpha/Numeric
Display)
- 7.25 inches high by 6.00 inches wide by 1.75 inches deep, including wiring connectors
- (18.45 cm by 15.25 cm by 4.45 cm)
• Enclosure
- 13 inches high by 9 inches wide by 4 inches deep
- (33.02 cm by 22.86 cm by 10.16 cm)
Operating Temperature/Humidity Range
•
0°F to 140°F (-18°C to 60°C)
• 0% to 90% Relative Humidity, non-condensing
Controller Power Requirements
•
12 VDC @ 1 A
Current Draw
•
maximum current draw 270 mA for a controller plus reader current draw (refer to Table 1 for Reader current draw)
• 120 mA max for a PXL-500/PXL-510 Controller
• 150 mA max for an SB-593 Satellite Board
NOTE: If an electronic locking device (such as a magnetic lock, a door strike, or similar device) is to be driven by the
same power supply as the PXL-500/PXL-510 controller, please ensure the power supply provides enough current to drive
every device connected to that supply plus an adequate safety margin. AC power is not recommended.
Controller Memory Retention
•
5 year lithium battery back up to support controller RAM and real-time clock
Output Relay Contact Rating
•
1 Amp @ 24 VDC
Input Device Configuration - 3 Inputs
•
Door Sense normally closed
• Request to Exit normally open
• Global Unlock normally open,
or Auxiliary RTE A-Door normally open
Table 1: Reader Current Draw
Reader Type
MS-3000 MS-4000 MS-5000 MS-7000
Current Draw 50 mA 50 mA 100 mA 200 mA
