2-15
Cisco XR 12406 Router Installation Guide
OL-13831-01
Chapter 2 Preparing for Installation
Installation Site Requirements
Power Connection Guidelines for AC-Powered Routers
When the Cisco XR 12406 Router operates with an AC PDU, observe these
guidelines:
• Original series Cisco XR 12406 routers: A power factor corrector (PFC)
allows the power supply to accept AC power source voltage from an AC
power source operating from 100 to 120 VAC 20-amp service in North
America, and a range of from 185 to 264 VAC 16-amp service in an
international environment.
• Enhanced series Cisco XR 12406 routers: Supports 220 VAC only which
requires 20-amp service in North America, and 16-amp service in an
international environment.
• Use only the 14-foot (4.3-meter) AC power cords shipped with the system.
• Provide a dedicated power source with its own circuit breaker for each
AC-input power supply installed in the router.
• Install an uninterruptable power source where possible.
Power plug types used in North America, Australia, and Europe are described in
Table 2-1 and shown in Figure 2-3 .
Table 2-1 AC-Input Power Cord International Options
Label Description Cisco Product Number
United States 110 VAC (original
Cisco XR 12000 series
routers) CAB-GSR6-US
United States 220 VAC (enhanced
Cisco XR 12000 series
routers) CAB-GSR6-220V-US
North America 20A, 250 VAC CAB-GSR16-US=
Australia, New Zealand 15A, 250 VAC CAB-GSR16-AU=
Europe, Argentina, Brazil 16A, 250 VAC CAB-GSR16-EU=
Italy 16A, 250 VAC CAB-GSR16-IT=
United Kingdom 13A, 250 VAC (13A
replaceable fuse) CAB-GSR16-UK=
