Cisco XR 12406 User Manual
Page 206
Chapter 5 Maintaining the Router
Removing and Replacing an RP or a Line Card
5-42
Cisco XR 12406 Router Installation Guide
OL-13831-01
Figure 5-27
Cisco XR 12406 Router Card Cage Slot Locations
57651
Line card
CSC
CSC
Power supply
Power supply
Alarm
Alarm
SFC
SFC
SFC
Line card
Line card
Line card
Line card
Route processor
Rack mounting
bracket holes
