A-7
Cisco XR 12406 Router Installation Guide
OL-13831-01
Appendix A Cisco XR 12406 Router Technical Specifications and Warnings
Compliance Information
Table A-7 Immunity Tests
Test Type or Specification Applies to Class/Level/Criteria
Electrostatic Discharge
EN61000-4-2:1995
System/enclosure Level 4/8KV contact, 15KV air/B
Radiated Immunity
IEC61000-4-3:1995
ENV50140:1993
System/enclosure Level 3/10V/m/A
1KHz 80% AM
(80MHz - 1 GHz)
Fast Transients
EN61000-4-4:1995
AC power lines
DC lines
Signal lines
Level 4/4 KV 2.5 kHz Rep Freq/B
Level 4/4 KV 2.5 kHz Rep Freq/B
Level 4/1 KV 5kHz Rep Freq/A
Level 4/2 KV 5kHz Rep Freq/B
Surge Immunity
EN61000-4-5:1995
AC power line (live-neutral)
2 ohms
AC power line (live-earth)
12 ohms
DC power line (live-earth)
DC Power line (return-earth)
Signal lines 2 ohms
Class 4/2KV/B
Class 4/4KV/B
Class 4/500V/B
Class 4/500V/B
Indoor: 500V
Outdoor: 4KV/R
Conducted RF Immunity
EN61000-4-6:1996+
ENV50141:1993
AC power line
DC power line
Signal lines
Level 3/10V/A
(150kHz-80MHz)
Voltage Dips + Sag
Interruptions
AC Power Lines
EN61000-4-11:1995
AC power lines 30% 10 ms (0.5 period)/B
30% 5000ms (25 periods)
60% 100 ms (5 periods)/C
60% 1000 ms (50 periods)
>95% 10ms (0.5 period)/C
>95% 5000 ms (250 periods)
