AC INVERTER PROGRAMMING INSTRUCTIONS
The WFC Series AC Inverters come wired for external use and must be installed for use in a side panel control (See
WIRING DIAGRAMS). Refer to owners manual for complete instructions and explanations. Manual used for the
following was FORM 1094.
After installation is complete the inverter must be reprogrammed to Cleveland's modifications of the factory settings. All
modifications are achieved in Access Level 2.
1. Turn agitator power on. The top four LED indicators will illuminate momentarily - wait for the three green LED's to go
out before proceeding.
2. Press the PROGram and SHIFT keys simultaneously to reach Access Level 2. The display display will now read:
3. Use the UP/DOWN arrow keys to select the program parameter for change.
4. Press the SHIFT key. The program number will blink indicating that that the data value may be changed.
5. Use the UP/DOWN arrow keys to select the new data code.
6. Press the ENTER key. The display will indicate **STORED** for one second, then revert to the normal parameter
display.
7. Press the PROGram key to exit the programming mode or the UP/DOWN keys to select an new parameter for
change.
PROGRAM CODE SUMMARY:
# Name Description Data Range Factory Setting Units Access Level Customer Setting
01 MODEL Model Number 0-65000 Note 1 --- 1
02 RVLVL Software Revision 0-640 Note 1 --- 2
03 IRAT Rated Current 2-200 Note 1 A 2
05 SERNO Serial Number 0-65000 --- --- 2
06 REP Repair Date 0-65000 --- --- 2
07 FLT3 Last Fault --- --- --- 1
08 FLT2 2nd Fault --- --- --- 2
09 FLT1 1st Fault --- --- --- 2
12 FOUT Output Frequency 0-400 --- Hz 1
13 VOUT Output Voltage 0-100 --- % 1
14 IOUT Output Current 0-650 --- A 1
15 LOAD Drive Load 0-200 --- % 1
16 TORQ Load Torque 0-200 --- % 1
17 TEMP Inverter Temp 2-105 --- C 1
18 TIME1 Total Run Time 0-65000 --- h 2
19 TIME2 Power On Hours 0-65000 --- h 2
21 MODE Input Mode 0-36 0 --- 1 4
24 FSEL Reference Select 0-18 0 --- 2
27 TLSEL Torque Limit Select 0-6 0 --- 2
31 FMIN Min. Frequency 0.00-400 0 Hz 1 14
32 FMAX Max. Frequency 20.00-400 60 Hz 1 70
33 F2 Preset Speed #2 - Jog 0.00-400 5 Hz 1
34 F3 Preset Speed #3 0.00-400 20 Hz 2
35 F4 Preset Speed #4 0.00-400 40 Hz 2
36 F5 Preset Speed #5 0.00-400 60 Hz 2
37 F6 Preset Speed #6 0.00-400 0 Hz 2
38 F7 Preset Speed #7 0.00-400 0 Hz 2
39 FTL Min. Frequency in Torque Limit 0.00-400 10 Hz 2
41 RSEL Ramp Selector 0-7 0 --- 2
42 ACC1 Acceleration Time #1 0.10-600 3 s 1 9
