IC Realtime 4 Channel Forensic Network Video Recorder User Manual
Page 85
76
Figure 4-94
4.2.7.1 HDD Management
Here is for you to view and implement hard disk management. See Figure 4-95.
You can see current HDD type, status, capacity and record time. When HDD is working properly,
system is shown as O. When HDD error occurred, system is shown as X.
z
Alarm set: Click alarm set button, the interface is shown as below. See Figure 4-96. (This
interface is just like the abnormity setup). Please refer to chapter 5.5.2 for detailed
information.
z
HDD operation: You can select HDD mode from the dropdown list such as read-only or you
can erase all data in the HDD. Please note system needs to reboot to get all the modification
activated.
Figure 4-95
Please highlight icon
to select the corresponding function.
