61
z Stop bit: Select stop bit.
z Parity: There are three choices: none/odd/even.
After completed all the setups please click save button, system goes back to the previous menu.
For detailed setup, please refer to chapter 4.9 preset/patrol/pattern/scan.
Figure 5-23
5.3.9 Display
Display setup interface is shown as below. See Figure 5-24.
z Transparency: Here is for you to adjust transparency. The value ranges from 128 to 255.
z Channel name: Here is for you to modify channel name. System max support 25-digit (The
value may vary due to different series). Please note all your modification here only applies to
10.2-inch combo DVR local end. You need to open web or client end to refresh channel
name.
z Time display: You can select to display time or not when system is playback.
z Channel display: You can select to channel name or not when system is playback.
z Resolution: There is only one option: 800×600.
z Display mode: you can select from the dropdown list.
z Enable tour: Activate tour function.
z Interval: Input proper interval value here. The value ranges from 5-120 seconds. In tour
process, you can use mouse or click Shift to turn on window switch function. Stands for
opening switch function, stands for closing switch function.
z Motion tour type: System support 1/8 window tour.
z Alarm tour type: System support 1/8 window tour.
Please highlight icon to select the corresponding function.
After completing all the setups please click save button, system goes back to the previous menu.
