AccuTab VI 14
The button toggles the digitizer alarm off and on. The button tests the digitizer
grid in the Active Area.
When using the AccuSet Menu, a tone will sound indicating a successful selection when you
click on the button. Four tones will sound when you click on the button. (See
the AccuTab VI Tones section of this manual for a complete table of the AccuTab VI tones.)
The number buttons through are active only after clicking on the button to
activate Select Mode.
Resetting the AccuTab VI
The AccuTab VI can be reset by:
 Turning off the power switch on the Connector Panel
 Unplugging and re-plugging the power supply
 Clicking on the AccuSet Menu.
When one of these events occurs, AccuTab VI will revert to the configuration that was last
defined. Any remote commands that were active before the reset will be lost.
Turning the Alarm Off and On
You can disable the alarm if you do not want to hear a tone each time the cursor button is
pressed. When the alarm is off, you will still hear diagnostic and menu-related tones.
To turn the alarm Off and On:
 To toggle the tones on or off, click on the button on the AccuSet Menu.
Testing the Active Area
To test the AccuTab VI grid, or Active Area:
1. Using the cursor, click on the button to activate the test.
