31
Servo connection by model type
The T8FGS transmitter channels are automatically assigned for optimal combination according to the
type selected with the Model Type function of the Linkage Menu. The channel assignment (initial setting)
for each model type is shown below. Connect the receiver and servos to match the type used.
*The set channels can be checked at the Function screen of the Linkage Menu. The channel assignments can also be changed. For
more information, read the description of the Function menu.
Airplane/glider
Normal wing and V-tail
● The above table shows the channel allocation at the FASST MLT2 mode.
● The wing types which can be selected depend on the FASST MLT2/MULT or 7-ch, selected.
(*1) These wing types are available on the MLT2, MULT and 7-ch mode. However, the ch8 doesn't work on the 7-ch mode.
(*2) This wing type is available on the MLT2, MULT and 7-ch mode. However, since the ch8 doesn't work on the 7-ch mode, please
assign the flap2 to another channnel which isn't used.
(*3) These wing types are available on the MLT2 and MULT mode only. (Except the airplane types on the MULT mode.)
RX
CH
1AIL (*1) 2AIL (*1) 2AIL+1FLAP (*1) 2AIL+2FLAP (*2) 2AIL+4FLAP (*3) 4AIL+2FLAP (*3)
Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider Airplane Glider
1 Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron Aileron
2 Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator Elevator
3 Throttle Motor Throttle Motor Throttle Motor Throttle Motor Rudder Rudder Rudder Rudder
4 Rudder Rudder Rudder Rudder Rudder Rudder Rudder Rudder Aileron2 Aileron2 Aileron2 Aileron2
5 Gear AUX7 Gear AUX7 Gear AUX6 Gear AUX5 Flap Flap Aileron3 Aileron3
6 VPP AUX6 Aileron2 Aileron2 Flap Flap Aileron2 Aileron2 Flap2 Flap2 Aileron4 Aileron4
7 AUX5 AUX5 VPP AUX6 Aileron2 Aileron2 Flap Flap Flap3 Flap3 Flap Flap
8 AUX4 AUX4 AUX5 AUX5 VPP AUX5 Flap2 Flap2 Flap4 Flap4 Flap2 Flap2
9/VC1 AUX1 AUX1 Camber Camber Camber Camber Camber Camber Camber Camber Camber Camber
10/VC2 AUX1 AUX1 AUX1 Butterfly AUX1 Butterfly VPP Butterfly Gear Butterfly Gear Butterfly
11/VC3 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 Throttle Motor Throttle Motor
12/VC4 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 AUX1 VPP AUX1 VPP AUX1
