112
● Select the function name
and return to the Model
menu by touching the
RTN button.
ELEVATOR
(RUDDER 2)
RUDDER
(ELEVATOR 2)
V-TAIL
V-TAIL [Corresponding model type]: Airplane/glider, V-tail
This function enables adjustments for left and
right rudder angle changes during elevator and
rudder operation of a V-tail airplane.
V-tail is when two servos are used together to
control rudder movement as elevators. In addition
to each elevator side moving up and down together,
each side moves in opposite directions when moving
as rudders. On a V-tail, this is also known as a
Ruddervator, as they serve the same purpose.
(Rudder function)
L e f t a n d r i g h t t r a v e l
a d j u s t m e n t o f r u d d e r
operation
(Elevator function)
Up and down travel adjustment of
elevator operation
● Select [V-TAIL] at the Model menu and
access the setup screen shown below
by touching the RTN button.
Scrolling
● Moving cursor
● Selecting mode
● Adjusting value
● To next page
Setting method
● Travel adjustment
Move the cursor to the item you want to
adjust and touch the RTN button to switch to
the data input mode.
Adjust the rate by scrolling the touch sensor.
Initial value: +50%
Adjustment range: -120~+120%
*When the RTN button is touched for one second, the rate is
reset to the initial value.)
Touch the RTN button to return to the cursor
mode.
*If the mixing direction is reversed, adjustments can be made
by changing the mixing rate polarity (+ or -).
*If a large value of travel is specified, when the sticks are
moved at the same time, the controls may bind or run out of
travel. Decrease the travel until no binding occurs.
