Futaba 8FGAS, 8FGHS 2.4GHz - Manual (Page 138)

138
Operation modes
The operation modes available when stick, trim
lever, or knob was selected are described below.
Linear mode [LIN]
This mode sets ON/OFF to the left or right (up
or down) with the set point as the reference.
Symmetrical mode [SYM]
Left and right (up and down) operations are
symmetrical near the neutral position. For instance,
when you want to switch D/R with the aileron
stick, when the stick is moved to the left or right,
DR can be turned on at the same position.
Shifting the ON/Off point
The ON/OFF point can be shifted. ON/OFF at
a free position can be changed.
●Black range: OFF range
●White range: ON range
[Setting method]
1. First, use the touch sensor to move the
cursor to the [POS] item.
2. Move the stick, trim lever, or knob to the
point you want to change and touch the
RTN button. The point is shifted.
3. To return to the preceeding screen, move
the cursor to the [ON/OFF] at the top of
the screen and touch the RTN button.
