Throttle trim (DT2)
Steering trim (DT1)
Steering trim
Throttle trim
F5/B5 or F7/B3
5 : 5 7 : 3
F5/B5 F7/B3
Forward side Brake side Forward side Brake side
41
In
itia
l S
et
-Up
Trims Initial Set-Up
- Steering trim (DT1) check
On the initial set-up, steering trim is assigned to the DT1 trim lever. Operate the lever
and make sure the marker moves on the ST graph. If default has been changed, test
steering trim in its new location. After checking the trim, set the trim display to the cen-
ter (N) position.
- Throttle trim (DT2) check
On the initial set-up, throttle trim is assigned to the DT2 trim lever. Operate the lever
and make sure the marker moves on the TH graph. If the default has been changed, test
the throttle trim in its new location. After checking the trim, set the trim display to the
center (N) position.
Throttle Mode Check
The throttle servo travel can be set to 5:5 or 7:3 for throttle stick operation as required
by the throttle mode function .
*This function is not available in "TH-STK : F10 mode".
