Installation, Receiver and servo connections – Futaba 4GRS User Manual
Page 33
Receiver
Switch
To Battery
Steering servo
Throttle servo
CH3 servo
CH4 servo
33
In
st
al
la
tio
n
Connect the receiver and servos as shown below. Connect and install the receiver and
servos in accordance with "Installation Safety Precautions" on the next page.
The figure shown below is an example. The method of connecting the motor controller
to the motor and battery depends on the motor controller used. Purchase the motor con-
troller and servos separately. The receiver also depends on the set.
Installation When An Electronic Speed Control Is Used
Installation For Gas Powered Models
Installation
Receiver and Servo Connections
