Telemetry "TELEMETRY"
Displays the log data elapsed time.
Displays the type of log data.
Displays the data
Receiver power supply voltage.
Receiver power supply voltage log.
Receiver power supply
voltage log
External power sup-
ply voltage log
Temperature sensor log RPM sensor log
1
(Log memory check)
Each time the (JOG) button is operated up or down the list is
scrolled 10 counts and each log data can be checked up to
200 counts.
2
When completed, return to the HOME screen by pressing
the (JOG) button.
Log list check method
Log Data List
The log data list can be called up when checking the log data memorized by logging op-
eration .
The maximum log data is up to 200 counts.
Refer to the map on page 116 for the log list screen.
Example: Receiver power supply voltage log list screen.
Refer to the below map for the display method of each log list screen.
