FT-11(D) Technical Manual, Rev. 1.35 November 2010 Page 8 of 52
3.4 Housing Dimensions
3.4.1 Desk Type Housing
Desk type front view Desk type side view
Desk type rear view Dimensions of Desk type housing with wall mount kit
3.4.2 Stainless Steel Housing
70
220
160
230
70
100
15
70
220
160
230
220
160
230
70
100
15
70
100
15
Stainless steel housing front view Stainless steel housing side view
100 mm deep with big backplane option
POWER 230 VAC, 50Hz, RS232
C
OPTIO
N
ANA
□
BIN
□
ETH
□
INT
□
MOD
□
I/O3 3
□
I/O4 8
LOAD CELL
S/N
187
179
155 195
140
