FT-11(D) Technical Manual, Rev. 1.35 November 2010 Page 6 of 52
3. Overview
The type FT-11(D) weight indicator is an economic and powerful state-of-the-art instrument. The accurate and
versatile instrument is available in different housings, meeting the industries demand for various environmental
conditions. FT-11(D) is approved by Weights & Measures Authorities for use in Accuracy Class III applications
with up to 10 000 intervals according to OIML R76. It has a large 6 digit LED weight display (red, 20 mm or 14
mm high) with weight status information. With a variety of interface options the FT-11(D) weight indicators are
the perfect fit to weighing systems and process control systems.
3.1 Key Features
FT-11D FT-11
EU Type approved for 10 000 intervals Yes Yes
Single or dual range Yes Yes
Approved sensitivity 0.4 V/e Yes
High internal resolution up to 8 000 000 counts Yes Yes
Display resolution up to 60 000 counts Yes Yes
Maximum conversion rate of 100/s Yes
Adaptive digital filter for fast and stable reading Yes Yes
High resolution display mode Yes Yes
Up to 6 load cells (350 ) or 18 load cells (1100 ) Yes
Up to 10 digital load cells (DLC); 16 if externally powered Yes
Automatic eccentricity adjustment Yes
Realtime clock No No
Standard Serial interface RS232C Yes Yes
Integrated AC power supply Yes Yes
Zeroing with one button & Taring with one button Yes Yes
Auto-zero tracking and auto-zero at power-up Yes Yes
Motion detection Yes Yes
Printout in different formats incl. header and footer Yes Yes
Isolated digital inputs / outputs Option Option
Setpoint monitoring (3 setpoints, digital I/O required) Yes Yes
Key lock option to prevent unauthorized access Yes Yes
3.2 Available Options and Accessoires
FT-11D FT-11
Alibi memory for up to 149 764 weighing results Yes Yes
Additional serial interface RS232C Yes Yes
Additional serial interface RS232C / 20 mA TTY CL / RS485 Yes* Yes*
Modbus RTU No Yes
Ethernet TCP/IP and Modbus RTU over Ethernet No Yes
Profibus DP-V0 & DP-V1 No Yes
ProfiNet No Yes
CANopen No Yes
Analogue output 0 – 10 V and 4 – 20 mA No Yes
Binary data output (17-bit code) No Yes
Digital inputs / outputs 3x / 3x 3x / 3x
12 V DC (12…17 V DC) power inlet No Yes
24 V DC (20…27 V DC) power inlet No Yes
Rechargeable battery (for 230 V AC version only) No Yes
Flintec IndFace Software No Yes
* 20 mA TTY CL not for stainless steel housing
