FT-11(D) Technical Manual, Rev. 1.35 November 2010 Page 32 of 52
9. Other I/O Options
9.1. Analogue Output Option (for FT-11 only)
FT-11 can be equipped with 4 – 20 mA or 0 – 10 V analogue output option. The value of the analogue output
changes in linear relationship to the displayed value. But if there is no numerical value on the display, the value
of the analogue output will be given as stated below:
Condition (On Display) 0 – 10 V output 4-20 mA output Alarm output
The weight value is higher than the weighing range (Over) 13 V 24 mA High
The weight value is lower than the zero range (Under) -1.4 V 0 mA High
Error [Err XX] 13 V 24 mA High
ADC is out of operating range [Adc Out] 13 V 24 mA High
As shown in the table above the linear range of the analogue output is limited between -1.4 V and 13 V
respective 0 mA and 24 mA.
9.1.1. Electrical Connections
There is an optically isolated input on the analogue card for zeroing the scale via an analogue output option
connector. The connections of the analogue output connector is given in the table below.
Pin no. for stainless steel housing
Description
Pin no. for Desk and panel types
(DB25 Female)
J10 connector
(Option 1)
JR1 / JR2 connector
(Option 2 or 3)
+ Zeroing input (+24V) 8 6 13
- Zeroing input ( 0V) 9 5 12
Alarm output 18 8 7
GND (Current / Voltage) 19 & 22 4 & 9 6 & 11
Iout (Current) 23 3 10
Vout (Voltage) 24 2 9
Shield D25 body 1 1
9.1.2. Setup
The analogue output is being adjusted digitally from the parameter group [4--].
[4--] Analogue Output Block
The calibration of the optional analogue output is performed in this sub-block.
[40-] Signal Selection
[400] Signal type*
0 = 4 – 20 mA 1 = 0 – 10 V DC *activated after saving the settings
[41-] Zero Adjustment (Signal level at load = 0 kg)
[410] Coarse Zero Adjustment
The coarse zero adjustment is being performed by pressing the key continuously to increase the
analogue signal level or the key to decrease the analogue signal level. The true load will be
ignored while adjusting.
[411] Fine Zero Adjustment
The fine zero adjustment is being performed by pressing the key repeatedly to increase the
analogue signal level or the key to decrease the analogue signal level. The true load will be
ignored while adjusting.
[42-] Span Adjustment (Signal level at maximum load)
[420] Coarse Span Adjustment
The coarse span adjustment is being performed by pressing the key continuously to increase the
analogue signal level or the key to decrease the analogue signal level. The full capacity value is
taken as the reference without loading any weight.
[421] Fine Span Adjustment
The fine span adjustment is being performed by pressing the key repeatedly to increase the
analogue signal level or the key to decrease the analogue signal level. The full capacity value is
taken as the reference without loading any weight.
