• press and the instrument will
show <>
If you have to gain access the “User” level
• press or for setting “ -19 “
• press and the instrument will
show Print Setup?
If you have to gain access the “Installer” level
• press or for setting “ 19 “
• press and the instrument will
show Print Setup?
If you have to select a parameter:
• press or
If you have to modify the value of the parameter:
• press and the instrument will
show <> and ...
• press or then ...
• press and
If you have to quit the procedure:
• do not operate for the time you have set with the parameter
Timeout Setup
If you modify the value of the parameter, the modification will
have effect as soon as you will quit the setting procedure.
5 SIGNALS
5.1 Signals
LED
on/off
alarm
set
timer
MEANING
ON/OFF LED
if it is lighted, the instrument will be in the ON mode
Alarm LED
if it flashes, an alarm will be running
Set LED
if it is lighted, the configuration parameters setting pro-
cedure will be running
if it flashes, the modification of the value of configura-
tion parameters will be running
Timer LED
if it is lighted, the Daily Report printing mode will be
running
3 PRINTING MODES
3.1 On Line Report
The instrument prints and stores the events; once the acquisi-
tion time you have set with the parameter Acq. Time has
passed, the instrument will print and store the values the probes
will be reading as well.
The parameter Off Line must have value No.
3.2 Daily Report
The instrument stores the events; once the acquisition time you
have set with the parameter Acq. Time has passed, the instru-
ment will store the values the probes will be reading as well.
The instrument will print the data it has stored at the time you
have set with the parameter Print Hour (1) .
The parameter Off Line must have value Yes and the param-
eter Print Hour must have values different from Off (2) .
(1) the instrument will print the data it has stored during the interval between two
times you have set with the parameter Print Hour
(2) you can use the Daily Report and Historical Report printing modes at the same
time.
3.3 Historical Report
The instrument stores the events; once the acquisition time you
have set with the parameter Acq. Time has passed, the instru-
ment will store the values the probes will be reading as well.
If you have to print the data the instrument has stored:
• press the instrument will show
Histor. Report?
• press within 10 s (3) .
The parameter Off Line must have value Yes (2) .
(2) you can use the Daily Report and Historical Report printing modes at the same
time
(3) if the parameter Remote Print has value Yes, you have to activate the input for
remote print.
4 CONFIGURATION PARAMETERS
4.1 How to set the configuration parameters
Configuration parameters are arranged on two levels (you can
select them according to the password you use).
If you have to gain access the procedure:
• press the instrument will
show password
