Evco S.p.A. Vroom | Hardware manual ver. 1.00 | Code 114VROOHWE00
page 20 of 22
Power supply:
according to the model:
- 12-24 VAC (min. 11.4 VAC, max. 27.6 VAC), 50/60 Hz, 3 VA (approximate) isolated or
15 ... 40 VDC, 3 W (approximate) isolated
- 24 VAC (min. 20.4 VAC, max. 27.6 VAC), 50/60 Hz, 3 VA (approximate) non isolated or
20 ... 40 VDC, 2 W (approximate) non isolated
supplied from a class 2 circuit.
The maximum length of the connecting cables of the power supply is 10 m (32.8 ft).
In the models with not isolated power supply, this must galvanically be isolated from the one of the
other devices connected in the network.
Protect the power supply with an UL listed or recognized fuse rated:
- 80 mA-T if the user interface is powered with 15... 40 VDC
- 160 mA-T if the user interface is powered with 12... 19 VAC
- 125 mA-T if the user interface is powered with 19... 24 VAC.
Overvoltage category: III.
Real time clock data maintenance in
absence of power supply:
2 days will battery fully charged.
Battery charging time 2 min without interruptions (the battery is charged by the power supply of the interface).
Alarm buzzer: incorporated.
Sensors:
incorporated, according to the model:
- temperature sensor
- temperature and humidity sensor.
Temperature sensor
Kind of sensor: digital.
Working range: from -10 to 70 °C.
Accuracy: ±1.5 °C.
Humidity sensor
Kind of sensor: digital.
Working range: from 5 to 95% of relative humidity.
Accuracy: ±3% of relative humidity from 20 to 80%, ±5% otherwise.
Display: 128 x 64 pixel single colour LCD graphic display (black with rearlighting through white LED).
Communication ports:
2 ports:
- 1 non optoisolated CAN port
- 1 programming port.
