Evco S.p.A. • Code 1049376E00 • page 3/8
• press twice or do not operate for 15 s: the LEDs and “1” will
switch-off, after which the instrument will exit the procedure.
It is also possible to set the work set-point of the core cooking phase
via parameter SP3 (for predefined setting 150 °C/°F).
To modify the core set-point:
• press
during modification of the work set-point: the upper part
of the display will show the core set-point, the
LEDs
and “2” will flash
• press or within 15 s; see also parameters r7 and r8
• press : the LEDs and “2” will switch-off, after which the
instrument will exit the procedure.
It is also possible to set the core set-point via parameter SP2 (for
predefined setting 150 °C/°F).
To go back to the previous level:
• press
during the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
The work set-point and the core set-point can also be modified when
the phase is in progress (these modifications are temporary, i.e., on the
contrary to any power supply cut-off, the selection of a different type
of cooking phase causes the reset of the same values set, however
with the procedure indicated in paragraph 5.3).
During the phase:
• the upper part of the display shows the established quantity with
parameter P5 (for predefined setting of the chamber temperature)
• the lower part of the display shows the core temperature
• press
and to display the indication relative to the cooking
phase in progress for 2 sec in the lower part of
the display (“COrE”).
When the core temperature reaches the core set-point, the phase
concludes.
On conclusion of the phase:
- the lower part of the display will show the flashing “End” indication
- the buzzer and the acoustic output are switched-on for the time
established using parameter c4
- press a key to silence the buzzer and to switch the acoustic output
off; press it again to delete the “End” indication
- the temperature regulation output is switched-off
- the fan is switched-off.
To interrupt the phase:
• press
for 1 s:
To memorise the phase and its settings in a program:
• make sure the phase has ended
• press
and for 4 s: the lower part of the display will show “PrOG”
and a flashing label relative to the first program
• repeat the procedure stated in paragraph 11.2.
The instrument memorises the phase and its settings on condition that
another phase is not selected on conclusion of the phase.
4.5
Steam cooking phase
To select the phase:
• make sure that the instrument is in the stand-by status, that no
procedure is in progress and the chamber probe error is not in progress
• press : the lower part of the display will show flashing “tinE”
• press or within 15 s to select “StEA”.
To exit the procedure in advance:
• press
do not operate for 15 s.
To start the phase:
• press
for 1 s:
To modify the work set-point:
• press
before starting the phase: the upper part of the display
will show the work set-point and the
LED will flash
• press or within 15 s; see also parameters r1 and r2
• press or do not operate for 15 s: the LED will switch-off,
after which the instrument will exit the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the work set-point of the steam cooking phase
via parameter SP4 (for predefined setting 150 °C/°F).
To modify the duration of the phase:
• press
and before starting the phase: the lower part of the
display will show phase duration, the left part
and the “timer” LED will flash.
The duration of the phase is visualised in the hours:minutes format.
To modify the hour:
• press
or within 15 s
• press : the right part will flash.
To modify the minutes:
• press
or within 15 s.
The duration of the phase can be set between 00:00 and 24:00 h:min.
• press
: the “timer” LED will switch-off, after which the instrument
will exit the procedure.
To go back to the previous level:
• press
during the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the duration of the steam cooking phase via
parameter d4 (for pre-defined setting 00:30 h:min).
To modify the parameter t2 (if t0 = 0, minimum duration of steam
injection; se t0 = 1, duration of steam injector switch-on):
• press
and before starting the phase: the lower part of the
display will show the value of parameter t2 and
the LED will flash
• press or within 15 s.
The parameter t2 can be set between 1 and 250 ds.
• press
: the LED will switch-off, after which the instrument will
exit the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
To modify parameter c7 (switch-on duration of the airhole in manual
mode):
• press
and before starting the phase: the lower part of the
display will show the value of parameter c7, the
left part and the LED will flash.
The value of the parameter c7 is displayed in the minutes:seconds
format.
To modify the minutes:
• press
or within 15 s
• press : the right part will flash.
To modify the seconds:
• press
or within 15 s.
The parameter c7 can be set between 00:00 and 60:00 min:s.
If the airhole is not managed by any digital output, the lower part of
the display will show “no” for 1 s.
• press
: the LED will switch-off, after which the instrument will
exit the procedure.
To go back to the previous level:
• press
during the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
The work set-point, the duration of the phase, parameter t2 and
parameter t7 can also be modified when the phase is in progress (these
modifications are temporary, i.e., on the contrary to any power supply
cut-off, the selection of a different type of cooking phase causes the
reset of the same values set, however with the procedure indicated in
paragraph 5.3).
If the duration of the phase is set at 00:00 h:min, the count will be
interrupted, the “timer” LED will switch-off, the buzzer and the acoustic
output will be on for 3 s.
During the phase:
• the upper part of the display shows the established quantity with
parameter P5 (for predefined setting of the chamber temperature)
• the lower part of the display shows the quantity established using
parameter P6 (for predefined setting of the count of the phase
duration; the count is displayed in the hours:minutes format (residual
time))
• press and to display the indication relative to the cooking
phase in progress for 2 sec in the lower part
of the display (“StEA”).
When the count of the duration of the phase is completed, the phase
is concluded.
Before the conclusion of the phase (of the time established with
parameter c9):
- the buzzer and the acoustic output are switched-on for the time
established using parameter c4.
On conclusion of the phase:
- the lower part of the display will show the flashing “End” indication
- press a key to silence the buzzer and to switch the acoustic output
off; press it again to delete the “End” indication
- the temperature regulation output is switched-off
- the fan is switched-off.
To interrupt the phase:
• press
for 1 s:
To memorise the phase and its settings in a program:
• make sure the phase has ended
• press
and for 4 s: the lower part of the display will show
“PrOG” and a flashing label relative to the first
program
• repeat the procedure stated in paragraph 11.2.
The instrument memorises the phase and its settings on condition that
another phase is not selected on conclusion of the phase.
4.6
Grill cooking phase
To select the phase:
• make sure that the instrument is in the stand-by status, that no
procedure is in progress and the chamber probe error is not in progress
• press : the lower part of the display will show flashing “tinE”
• press or within 15 s to select “GriL”.
To exit the procedure in advance:
• press
do not operate for 15 s.
To start the phase:
• press
for 1 s:
If the pre-heating phase is not enabled (parameter r11 = 0), the “GriL”
label will not be displayed.
To modify the work set-point:
• press
before starting the phase: the upper part of the display
will show the work set-point and the
LED will flash
• press or within 15 s; see also parameters r1 and r2
• press or do not operate for 15 s: the LED will switch-off,
after which the instrument will exit the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the work set-point of the grill cooking phase via
parameter SP5 (for predefined setting 150 °C/°F).
To modify the duration of the phase:
• press
and before starting the phase: the lower part of the
display will show phase duration, the left part
and the “timer” LED will flash.
The duration of the phase is visualised in the hours:minutes format.
To modify the hour:
• press
or within 15 s
• press : the right part will flash.
To modify the minutes:
• press
or within 15 s.
The duration of the phase can be set between 00:00 and 24:00 h:min.
• press
: the “timer” LED will switch-off, after which the instrument
will exit the procedure.
To go back to the previous level:
• press
during the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the duration of the grill cooking phase via
parameter d5 (for pre-defined setting 00:30 h:min).
To modify the switch-on duration of the grill (intended as a percentage
of the time established using parameter c1):
• press
before starting the phase: the lower part of the display will
show the duration of switch-on of the grill and the LED
will flash
The duration of the phase is visualised in the 0 .. format. 100%.
• press
or within 15 s
• press : the LED will switch-off, after which the instrument will
exit the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the switch-on duration of the grill via parameter
c11 (for predefined setting 25%).
The work set-point, the duration of the phase and the switch-on
duration of the grill can also be modified when the phase is in progress
(these modifications are temporary, i.e., on the contrary to any power
supply cut-off, the selection of a different type of cooking phase causes
the reset of the same values set, however with the procedure indicated
in paragraph 5.3).
If the duration of the phase is set at 00:00 h:min, the count will be
interrupted, the “timer” LED will switch-off, the buzzer and the acoustic
output will be on for 3 s.
During the phase:
• the upper part of the display shows the established quantity with
parameter P5 (for predefined setting of the chamber temperature)
• the lower part of the display shows the quantity established using
parameter P6 (for predefined setting of the count of the phase
duration; the count is displayed in the hours:minutes format (residual
time))
• press and to display the indication relative to the cooking
phase in progress for 2 sec in the lower part of
the display (“GriL”).
When the count of the duration of the phase is completed, the phase
is concluded.
Before the conclusion of the phase (of the time established with
parameter c9):
- the buzzer and the acoustic output are switched-on for the time
established using parameter c4.
On conclusion of the phase:
- the lower part of the display will show the flashing “End” indication
- press a key to silence the buzzer and to switch the acoustic output
off; press it again to delete the “End” indication
- the temperature regulation output is switched-off
- the fan is switched-off.
To interrupt the phase:
• press
for 1 s:
To memorise the phase and its settings in a program:
• make sure the phase has ended
• press
and for 4 s: the lower part of the display will show
“PrOG” and a flashing label relative to the first
program
• repeat the procedure stated in paragraph 11.2.
The instrument memorises the phase and its settings on condition that
another phase is not selected on conclusion of the phase.
4.7
Continuous cooking phase
To select the phase:
• make sure that the instrument is in the stand-by status, that no
procedure is in progress and the chamber probe error is not in progress
• press : the lower part of the display will show flashing “tinE”
• press or within 15 s to select “COnt”.
To exit the procedure in advance:
• press
do not operate for 15 s.
To start the phase:
• press
for 1 s:
To modify the work set-point:
• press
before starting the phase: the upper part of the display
will show the work set-point and the
LED will flash
• press or within 15 s; see also parameters r1 and r2
• press or do not operate for 15 s: the LED will switch-off,
after which the instrument will exit the procedure.
To exit the procedure in advance:
• do not operate for 15 s (any modifications will be saved).
It is also possible to set the work set-point of the continuous cooking
phase via parameter SP6 (for predefined setting 150 °C/°F).
The work set-point can also be modified when the phase is in progress (this
modification is temporary, i.e., on the contrary to any power supply cut-off,
the selection of a different type of cooking phase causes the reset of the
same value set, however with the procedure indicated in paragraph 5.3).
