Channel Value Function
6 PROGRAMS/SOUND ACTIVITY
168 - 175 SOUND MODE 5
176 - 183 SOUND MODE 6
184 - 191 SOUND MODE 7
192 - 199 SOUND MODE 8
200 - 207 SOUND MODE 9
208 - 215 SOUND MODE 10
216 - 223 SOUND MODE 11
224 - 231 SOUND MODE 12
232 - 239 SOUND MODE 13
240 - 247 SOUND MODE 14
248 - 255 SOUND MODE 15
7 MASTER DIMMER
1 - 255 0% - 100%
Tri Disc 9 IR 7 Channel - DMX Values & Functions
Channels 1, 2, and 3 will not work, when Channel 4 is being used.
When using Channel 6 values 8-135, Channel 5 will control the speed of the programs.
When using Channel 6 values 136-255, Channel 5 will control the sound sensitivity. Sound sen-
sitivity control will start working after Channel 5 is past the DMX value of 31.
Channel Value Function
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
4 1 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
5 STROBING/PROGRAM SPEED
0 - 15 NOTHING
16 - 255 STROBING/SPEED CONTROL
SLOW - FAST
6 PROGRAMS/SOUND ACTIVITY
0 - 7 OFF
8 - 15 PROGRAM 1
16 - 23 PROGRAM 2
24 - 31 PROGRAM 3
32 - 39 PROGRAM 4
40 - 47 PROGRAM 5
48 - 55 PROGRAM 6
56 - 63 PROGRAM 7
64 - 71 PROGRAM 8
72 - 79 PROGRAM 9
80 - 87 PROGRAM 10
88 - 95 PROGRAM 11
96 - 103 PROGRAM 12
104 - 111 PROGRAM 13
112 - 119 PROGRAM 14
120 - 127 PROGRAM 15
128 - 135 PROGRAM 16
136 - 143 SOUND MODE 1
144 - 151 SOUND MODE 2
152 - 159 SOUND MODE 3
160 - 167 SOUND MODE 4
Tri Disc 9 IR 7 Channel - DMX Values & Functions
