Tri Disc 9 IR Electro IRC Operation
The Electro IRC remote (sold seperately) has many different functions
and allows you to control your Tri Disc 9 IR from long distance. The
Electro IRC remote can control your system up to 30 ft. To use the re-
mote you must first activate the fixtures receiver, to activate the receiver
please see the instructions on page 9.
Controls and Functions:
1. Black Out - This button will black out the unit.
2. Select Prog - This button will allow you to access the auto
run mode and built in programs. Each press of the button will
change to the next mode.
3. Flash - This button will activate the strobe function. Use the
“+” & “-” buttons to adjust the strobe speed.
4. SPEED - Press this button to activate and use the “+” & “-”
buttons to adjust the speed of the color fade mode and color
change mode.
5. DMX Mode - Activates DMX Mode.
6. Set Addr - Press this button to set the DMX address. Press
this button first, then press the numbers to set the address.
Example: Set DMX Address 1 Press “S-0-0-1”
Set DMX Address 245 Press “S-2-4-5”
7. SL/SA (Slave/Sound Active) - This button lets you switch
between Slave mode in a Master-Slave configuration and Sound
Active mode. When the fixture is in Sound Active mode, use the
“+” & “-” buttons to adjust the sound sensitivity.
8. R G B A W - Press either one of these buttons and the press
the “+” or “-” to adjust the brightness. Press the Flash Button
to activate strobing and use the “+” & “-” buttons to adjust the
strobe speed. The “A” & “W” buttons will not work with this unit.
9. “+” and “-” - Use these buttons to adjust the flash rate
speed, program speed, sound sensitivity, and program selec-
tion.
Tri Disc 9 IR 1 Channel - DMX Values & Functions
Channel Value
Function
1
COLOR MACROS
0 - 10 OFF
11 - 17 BASTARD AMBER
18 - 24 MEDIUM AMBER
25 - 31 PALE AMBER GOLD
32 - 38 GALLO GOLD
39 - 45 GOLDEN AMBER
46 - 52 LIGHT RED
53 - 59 MEDIUM RED
60 - 66 MEDIUM PINK
67 - 73 BROADWAY PINK
74 - 80 FOLLIES PINK
81 - 87 LIGHT LAVENDER
88 - 94 SPECIAL LAVENDER
95 - 101 LAVENDER
102 - 108 INDIGO
109 - 115 HEMSLEY BLUE
116 - 122 TIPTON BLUE
123 - 129 LIGHT STEEL BLUE
130 - 136 LIGHT SKY BLUE
137 - 143 SKY BLUE
144 - 150 BRILLIANT BLUE
151 - 157 LIGHT GREEN BLUE
158 - 164 BRIGHT BLUE
165 - 171 PRIMARY BLUE
172 - 178 CONGO BLUE
179 - 185 PALE YELLOW GREEN
186 - 192 MOSS GREEN
193 - 199 PRIMARY GREEN
200 - 206 DOUBLE CTB
207 - 213 FULL CTB
214 - 220 HALF CTB
221 - 227 DARK BLUE
228 - 234 WHITE
235 - 241 FULL RED
242 - 248 FULL GREEN
249 - 255 FULL BLUE
