Eliminator Lighting TRiDiSC 9 IR User Manual
Page 7
Eliminator Lighting - www.eliminatorlighting.com - Tri Disc 9 IR User Manual - Page 13
Eliminator Lighting - www.eliminatorlighting.com - Tri Disc 9 IR User Manual - Page 14
Tri Disc 9 IR 2 Channel - DMX Values & Functions
Channel Value
Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
Tri Disc 9 IR 3 Channel - DMX Values & Functions
Channel Value
Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
Tri Disc 9 IR 4 Channel - DMX Values & Functions
Channel Value
Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 MASTER DIMMER
0 - 255 0% - 100%
Channels 1, 2, and 3 will not work, when Channel 4 is being
used.
Channel Value
Function
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
4 1 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
5 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
6 MASTER DIMMER
1 - 255 0% - 100%
Tri Disc 9 IR 6 Channel - DMX Values & Functions
Channels 1, 2, and 3 will not work, when Channel 5 is being
used.
Channel Value
Function
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
4 MASTER DIMMER
1 - 255 0% - 100%
5 1 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
Tri Disc 9 IR 5 Channel - DMX Values & Functions
