Tri Disc 9 IR Operating Instructions
• To run the 5 Channel Mode, press the MODE button until “Ch05”
is displayed. This is the 5 Channel DMX Mode.
• To run the 6 Channel Mode, press the MODE button until “Ch06”
is displayed. This is the 6 Channel DMX Mode.
• To run the 7 Channel Mode, press the MODE button until “Ch07”
is displayed. This is the 7 Channel DMX Mode.
5. Please see pages 13-17 for DMX values and traits.
6. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX control-
ler.
Default Running Mode:
This is a default running mode. When this mode is activated all modes
will return to their default settings.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents either “on” or “oFF”.
2. Press the SET UP button until “dEFA” is displayed.
3. Press the UP and DOWN buttons simultaneously. Press the
MODE button to exit.
Electro IRC:
This function is used to activate and deactivate the Electro IRX
(Remote Control). When this function is activated you can control the
fixture using the Electro IRC. Please see the page 11 for the controls
and functions.
1. Plug the fixture in and press the MODE button until “dXX” is dis-
played. “XX” represents “on” or “off”.
2. Press the SET UP button until “IrXX” is displayed. “XX” repre-
sents either “on” or “oF”.
3. Press the UP or DOWN buttons to either activate the remote func-
tion (On) or deactivate it (Off).
Eliminator Lighting - www.eliminatorlighting.com - Tri Disc 9 IR User Manual - Page 10
Tri Disc 9 IR Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave
mode. In Master-Slave operation one unit will act as the controlling unit
and the others will react to the controlling units built-in programs. Any
unit can act as a Master or as a Slave however, only one unit can be pro-
grammed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit.
Use standard XLR data cables to link your units together. Remember
that the Male XLR connector is the input and the Female XLR con-
nector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the
male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. For the “Slave” units just connect them to the “Master”, they will start
following the “Master” as soon as they are connected .
