Tri Disc 9 IR Specifications
Model: Tri Disc 9 IR
Voltage: 100V ~ 240V/50~60Hz
LEDs: 9 x 3W TRI LEDs (RGB 3-in-1)
Beam Angle: 40 Degrees
Working Position: Any safe working position
Power Draw: 35W
Power Cord Daisy Chain: 16 Fixtures Max.
Fuse: 2 Amp
Weight: 3.9lbs./ 1.8Kgs.
Dimensions: 10.5” (L) x 10” (W) x 3.5” (H)
263 x 250 x 88mm
Colors: RGB Color Mixing
DMX Channels: 7 DMX Modes: 1 Channel Mode, 2
Channel Mode, 3 Channel Mode, 4
Channel Mode, 5 Channel Mode,
6 Channel Mode, & 7 Channel
Mode
Warranty: 1 Year (365 days)
Please Note: Specifications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Auto Sensing Voltage: This fixture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
