Compex Technologies NP25G 6C - Manual (Page 61)

Page 56
1. Under the CONFIGURATION
command menu, click on
Routing to be brought to the
System Routing Table shown (on
the right).
Initially, the table will contain
the default routing entries built
into the router.
2. Click on the Static Routing Table
button above.
3. On this page, click the Add
button.
4. You may specify the Destination
IP Address, Destination Net
Mask and Gateway IP Address
here. For this example, they are
192.168.100.0, 255.255.255.0 and
192.168.168.254 respectively. Hit
the Add button to finish.
When the entry is added, it is
reflected in the Static Routing
Table.
