Compex Technologies NP25G 6C - Manual (Page 108)

Page 103
Appendix: View the Technical
Specifications
Industry Standards Wired:
- IEEE 802.3 10Base-T
- IEEE 802.3u 100Base-Tx
- IEEE 802.3x Flow Control
Wireless:
- IEEE 802.11b
- IEEE 802.11g
WAN Interface - 1x Auto MDI/MDI-X RJ45 Ethernet
Port for external Cable/ADSL
modem
WAN Type - Static IP
- Dynamic IP
- PPP over Ethernet (PPPoE)
- Point to Point Tunneling Protocol
(PPTP)
- L2TP
LAN/WLAN Interface Wired:
- Integrated 4x Auto MDI/MDI-X
10/100Mbps Switch
Wireless:
- Operating channels, frequency of:
11 Channels 2.412~2.462, US,
Canada
13 Channels, 2.412~2.472, Europe
14 Channels 2.412~2.484, Japan
- Direct Sequence Spread Spectrum
modulation, Orthogonal Frequency
Division Multiplexing modulation
-
Data rates: 54Mbps, 48Mbps,
36Mbps, 24Mbps, 18Mbps, 12Mbps,
9Mbps, 6Mbps, 5.5Mbps, 2Mbps,
1Mbps
- Security:
WEP
WPA-Personal
