Setup WAN for Cable Internet with Static IP
Assignment
If you have an ISP that leases a static WAN IP for your subscription, you will need to
configure your router’s WAN type accordingly. For example, if the ISP provided you
with the following setup information, you can set up your WAN as described below:
IP Address :
203.120.12.47
Network Mask
:
255.255.255.0
Gateway IP Address
:
203.120.12.15
1. Under the CONFIGURATION on the command menu, click on WAN Setup.
2. Access the Select WAN Type page
and choose Static IP Address before
clicking the Apply button. You will
then be brought to the following
page requiring your inputs.
3. Fill in the information provided by
your ISP in the IP Address, Network
Mask and Gateway IP Address
fields, before clicking the Apply
button.
4. Please remember to click Reboot
Router under SYSTEM TOOLS and hit
the Reboot button to let the settings
take effect.
