Opus Card – DDR-2 Interface

Reference Manual

12/03/2010 07:35 AM

8

Copyright © 2009-2010 by CML

2.3.2 Non-burst, 64-bit Memory Write
The diagram below is for a non-burst memory write to a single 64-bit word. The Bus2IP_BE bus
is used to determine which bytes to write in the 64-bit word. The use of the Bus2IP_BE bus
enables the hardware controlling the PLB slave to also write eight, sixteen, or thirty-two bit
values to a 64-bit memory location.

1

2

3

4

5

6

7

8

9

10

11

Write

Address

Word1

Word2

Mask1

Mask2

64-bit Data

Address

Byte Enables

Idle

Wait_WrReq

Wr_Word1

Wr_Word2

Idle

TimeGen

DDR2_Clk

Bus2IP_Clk

Bus2IP_CS

Bus2IP_RNW

Bus2IP_Addr

Bus2IP_BE

Bus2IP_WrReq

Bus2IP_Data

IP2Bus_AddrAck

IP2Bus_WrAck

App_AF_WREn

App_AF_Cmd

App_AF_Addr

App_WDF_WREn

App_WDF_Data

App_WDF_Mask_Data

State
