chipKIT™ Max32™ Board Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 20 of 20
CHIPKIT and the CHIPKIT Logo are trademarks or registered trademarks of Microchip Technology Incorporated in
the U.S. and other countries, and are used under license.
PIC32 Pin # Connector Pin # chipKIT Pin # PIC32 Signal Notes
80 J14-14 76 ETXD3/PMD13/CN19/RD13
81 J3-05 10 OC5/PMWR/CN13/RD4
82 J8-15 39 PMRD/CN14/RD5
83 J8-07 47 ETXEN/PMD14/CN15/RD6
84 J14-16 77 ETXCLK/PMD15/CN16/RD7
85 VCAP/VDDCORE
86 VDD
87 J8-09 45 C1RX/ETXD1/PMD11/RF0
88 J8-08 46 C1TX/ETXD0/RMD10/RF1
89 J3-02 78 C2TX/ETXERR/PMD9/RG1
90 J3-04 79 C2RX/PMD8/RG0
91 J3-06 80 TRCLK/RA6
92 J3-08 81 TRD3/RA7
93 J9-01 37 PMD0/RE0
94 J9-02 36 PMD1/RE1
95 J3-10 82 TRD2/RG14
96 J3-12 83 TRD1/RG12
97 J3-14 84 TRD0/RG13
98 J9-03 35 PMD2/RE2
99 J9-04 34 PMD3/RE3
100 J9-05 33 PMD4/RE4
