3.7.2 Pinout Table by Connector Pin
chipKIT Pin #
Connector Pin #
PIC32 Pin #
PIC32 Signal
Notes
75
J14-12
73
SOSCI/CN1/RC13
76
J14-14
80
ETXD3/PMD13/CN19/RD13
77
J14-16
84
ETXCLK/PMD15/CN16/RD7
78
J3-02
89
C2TX/ETXERR/PMD9/RG1
79
J3-04
90
C2RX/PMD8/RG0
80
J3-06
91
TRCLK/RA6
81
J3-08
92
TRD3/RA7
82
J3-10
95
TRD2/RG14
83
J3-12
96
TRD1/RG12
84
J3-14
97
TRD0/RG13
85
J3-16
28
VREF-/CVREF0/AERXD2/PMA7/RA9
Connector Pin #
chipKIT Pin #
PIC32 Pin #
PIC32 Signal
Notes
J03-01
8
79
ETXD2/IC5/PMD12/RD12
J03-02
78
89
C2TX/ETXERR/PMD9/RG1
J03-03
9
78
OC4/RD3
J03-04
79
90
C2RX/PMD8/RG0
J03-05
10
81
OC5/PMWR/CN13/RD4
J03-06
80
91
TRCLK/RA6
J03-07
11
9
T5CK/SDI1/RC4
J03-08
81
92
TRD3/RA7
J03-09
12
58
SCL2/RA2
J03-10
82
95
TRD2/RG14
J03-11
13
59
SDA2/RA3
J03-12
83
96
TRD1/RG12
J03-13
GND
J03-14
84
97
TRD0/RG13
J03-15
44
29
VREF+/CVREF+/AERXD3/PMA6/RA10
AREF
J03-16
85
28
VREF-/CVREF0/AERXD2/PMA7/RA9
J04-01
21
66
AETXCLK/SCL1/INT3/RA14
J04-02
20
67
AETXEN/SDA1/INT4/RA15
J04-03
19
47
AETXD0/SS1A/U1BRX/U1ACTS/CN20/
RD14
