3.7.3 Pinout Table by Microcontroller Pin
Connector Pin #
chipKIT Pin #
PIC32 Pin #
PIC32 Signal
Notes
J14-07
3
72
SDO1/OC1/INT0/RD0
J14-08
73
61
TDO/RA5
J14-09
4
74
SOSCO/T1CK/CN0/RC14
J14-10
74
69
SS1/IC2/RD9
J14-11
5
76
OC2/RD1
J14-12
75
73
SOSCI/CN1/RC13
J14-13
6
77
OC3/RD2
J14-14
76
80
ETXD3/PMD13/CN19/RD13
J14-15
7
19
AERXD1/INT2/RE9
J14-16
77
84
ETXCLK/PMD15/CN16/RD7
J18-01
21
66
AETXCLK/SCL1/INT3/RA14
J18-02
20
67
AETXEN/SDA1/INT4/RA15
PIC32 Pin #
Connector Pin #
chipKIT Pin #
PIC32 Signal
Notes
1
J9-10
28
AERXERR/RG15
2
VDD
3
J9-06
32
PMD5/RE5
4
J9-07
31
PMD6/RE6
5
J9-08
30
PMD7/RE7
6
n/c
n/c
T2CK/RC1
7
J9-16
22
T3CK/AC2TX/RC2
8
J9-15
23
T4CK/AC2RX/RC3
9
J3-07
11
T5CK/SDI1/RC4
10
J8-02
52
ECOL/SCK2A/U2BTX/U2ARTS/PMA5/C
N8/RG6
Also J13-03
11
J9-09
29
ECRS/SDA2/SDI2A/U2ARX/PMA4/CN9
/RG7
Also JP3, JP4
12
J8-11
43
ERXDV/AERXDV/ECRSDV/AECRSDV/SC
L2A/SDO2A/
U2ATX/PMA3/CN10/RG8
Also JP3, JP4
13
J10-01
MCLR
14
J8-01
53
ERXCLK/AERXCLK/EREFCLK/AEREFCLK/
SS2A/U2BRX/
U2ACTS/PMA2/CN11/RG9
Also J13-05
15
VSS
