chipKIT™ Max32™ Board Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 16 of 20
Connector Pin #
chipKIT Pin #
PIC32 Pin #
PIC32 Signal
Notes
J08-09
45
87
C1RX/ETXD1/PMD11/RF0
J08-10
44
29
VREF+/CVREF+/AERXD3/PMA6/RA10
J08-11
43
12
ERXDV/AERXDV/ECRSDV/AECRSDV/S
CL2A/SDO2A/U2ATX/
PMA3/CN10/RG8
Also JP3, JP4,
J03-15
J08-15
39
82
PMRD/CN14/RD5
J08-16
38
70
SCK1/IC3/PMCS2/PMA15/RD10
J09-01
37
93
PMD0/RE0
J09-02
36
94
PMD1/RE1
J09-03
35
98
PMD2/RE2
J09-04
34
99
PMD3/RE3
J09-05
33
100
PMD4/RE4
J09-06
32
3
PMD5/RE5
J09-07
31
4
PMD6/RE6
J09-08
30
5
PMD7/RE7
J09-09
29
11
ECRX/SDA2/SDI2A/U2ARX/PMA4/CN
9/RG7
Also JP3, JP4
J09-10
28
1
AERXERR/RG15
J09-11
27
57
D+/RG2
J09-12
26
56
D-/RG3
J09-13
25
51
USBID/RF3
J09-14
24
54
VBUS (note useable as I/O)
J09-15
23
8
T4CK/AC2RX/RC3
J09-16
22
7
T3CK/AC2TX/RC2
J10-01
13
MCLR
J10-02
VCC3V3
J10-03
VCC5V0
J10-04
GND
J10-05
GND
J10-06
VIN (external supply voltage)
J14-01
0
52
SDA1A/SDI1A/U1ARX/RF2
J14-02
70
17
TMS/RA0
J14-03
1
53
SCL1A/SDO1A/U1ATX/RF8
J14-04
71
38
TCK/RA1
J14-05
2
18
AERXD0/INT1/RE8
J14-06
72
60
TDI/RA4
