chipKIT™ Max32™ Board Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 12 of 20
chipKIT Pin #
Connector Pin #
PIC32 Pin #
PIC32 Signal
Notes
15
J4-07
40
AC1RX/SS3A/U3BRX/U3ACTS/RF12
16
J4-06
50
SCL3A/SDO3A/U3ATX/PMA8/CN18/R
F5
17
J4-05
49
SDA3A/SDI3A/U3ARX/PMA9/CN17/RF
4
18
J4-04
48
AETXD1/SCK1A/U1BTX/U1ARTS/CN21
/RD15
19
J4-03
47
AETXD0/SS1A/U1BRX/U1ACTS/CN20/
RD14
20
J4-02, J18-02
67
AETXEN/SDA1/INT4/RA15
21
J4-01, J18-01
66
AETXCLK/SCL1/INT3/RA14
22
J9-16
7
T3CK/AC2TX/RC2
23
J9-15
8
T4CK/AC2RX/RC3
24
J9-14
54
VBUS
25
J9-13
51
USBID/RF3
26
J9-12
56
D-/RG3
27
J9-11
57
D+/RG2
28
J9-10
1
AERXERR/RG15
29
J9-09
11
ECRX/SDA2/SDI2A/U2ARX/PMA4/CN9
/RG7
30
J9-08
5
PMD7/RE7
31
J9-07
4
PMD6/RE6
32
J9-06
3
PMD5/RE5
33
J9-05
100
PMD4/RE4
34
J9-04
99
PMD3/RE3
35
J9-03
98
PMD2/RE2
36
J9-02
94
PMD1/RE1
37
J9-01
93
PMD0/RE0
38
J8-16
70
SCK1/IC3/PMCS2/PMA15/RD10
39
J8-15
82
PMRD/CN14/RD5
40
J8-14
35
AN11/EREXERR/AETXERR/PMA12/RB
11
Also J7-04(65)
41
J8-13
42
AN13/ERXD1/AECOL/PMA10/RB13
Also J7-06(66)
42
J8-12
41
AN12/ERXD0/AECRS/PMA11/RB12
Also J7-05(67)
43
J8-11
12
ERXDV/AERXDV/ECRSDV/AECRSDV/S
CL2A/SDO2A/
U2ATX/PMA3/CN10/RG8
Also JP3,JP4
44
J8-10
29
VREF+/CVREF+/AERXD3/PMA6/RA10
Also J3-15
45
J8-09
87
C1RX/ETXD1/PMD11/RF0
