chipKIT™ Max32™ Board Reference Manual
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
Page 18 of 20
PIC32 Pin #
Connector Pin #
chipKIT Pin #
PIC32 Signal
Notes
16
VDD
17
J14-02
70
TMS/RA0
18
J14-05
2
AERXD0/INT1/RE8
19
J14-15
7
AERXD1/INT2/RE9
20
J5-06
59
AN5/C1IN+/VBUSON/CN7/RB5
Also A5
21
J5-05
58
AN4/C1IN-/CN6/RB4
Also A4
22
J5-04
57
AN3/C2IN+/CN5/RB3
Also A3
23
J5-03
56
AN2/C2IN-/CN4/RB2
Also A2
24
J5-02
55
PGEC1/AN1/CN3/RB1
Also A1
25
J5-01
54
PGED1/AN0/CN2/RB0
Also A0
26
J5-7
60
PGEC2/AN6/OCFA/RB6
Also A6
27
J5-8
61
PGED2/AN7/RB7
Also A7
28
J3-16
85
VREF-/CVREF-/AERXD2/PMA7/RA9
29
J8-10
44
VREF+/CVREF+/AERXD3/PMA6/RA10
Also J3-15
30
AVDD
31
AVSS
32
J7-01
62
AN8/C1OUT/RB8
Also A8
33
J7-02
63
AN9/C2OUT/RB9
Also A9
34
J7-03
64
AN10/CVREFOUT/PMA13/RB10
Also A10
35
J7-04
65
AN11/EREXERR/AETXERR/PMA12/RB1
1
Also A11, J8-
14(40)
36
VSS
37
VDD
38
J14-04
71
TCK/RA1
39
J4-08
14
AC1TX/SCK3A/U3BTX/U3ARTS/RF13
40
J4-07
15
AC1RX/SS3A/U3BRX/U3ACTS/RF12
41
J7-05
67
AN12/ERXD0/AECRS/PMA11/RB12
Also A12, J8-
12(42)
42
J7-06
66
AN13/ERXD1/AECOL/PMA10/RB13
Also A13, J8-
13(41)
43
J7-07
68
AN14/ERXD2/AETXD3/PMALH/PMA1/
RB14
Also A14
44
J7-08
69
AN15/ERXD3/AETXD2/OCFB/PMALL/P
MA0/CN12/RB15
Also A15
45
VSS
46
VDD
47
J4-03
19
AETXD0/SS1A/U1BRX/U1ACTS/CN20/
RD14
