NetFPGA-1G-CML™ Board Reference Manual
NET FMC_HA04_N LOC = U25;
NET FMC_HA05_P LOC = V26;
NET FMC_HA05_N LOC = U26;
NET FMC_HA06_P LOC = AD25;
NET FMC_HA06_N LOC = AE25;
NET FMC_HA07_P LOC = AD21;
NET FMC_HA07_N LOC = AE21;
NET FMC_HA08_P LOC = AE22;
NET FMC_HA08_N LOC = AF22;
NET FMC_HA09_P LOC = R18;
NET FMC_HA09_N LOC = P18;
NET FMC_HA10_P LOC = U16;
NET FMC_HA10_N LOC = N16;
NET FMC_HA11_P LOC = Y20;
NET FMC_HA11_N LOC = U21;
NET FMC_CLK0_M2C_N LOC = P21;
NET FMC_CLK0_M2C_P LOC = R21;
NET FMC_CLK1_M2C_N LOC = AC24;
NET FMC_CLK1_M2C_P LOC = AC23;
NET FMC_CLK2_M2C_N LOC = AB24;
NET FMC_CLK2_M2C_P LOC = AA23;
NET FMC_CLK3_M2C_N LOC = AA24;
NET FMC_CLK3_M2C_P LOC = Y23;
NET FMC_DP0_M2C_N LOC = C3;
NET FMC_DP0_M2C_P LOC = C4;
NET FMC_DP0_C2M_N LOC = A3;
NET FMC_DP0_C2M_P LOC = A4;
NET FMC_DP1_M2C_N LOC = E3;
NET FMC_DP1_M2C_P LOC = E4;
NET FMC_DP1_C2M_N LOC = D1;
