NetFPGA-1G-CML™ Board Reference Manual
NET FMC_LA07_N
LOC = AC26;
NET FMC_LA08_P LOC = AD26;
NET FMC_LA08_N LOC = AE26;
NET FMC_LA09_P LOC = Y25;
NET FMC_LA09_N LOC = Y26;
NET FMC_LA10_P LOC = W21;
NET FMC_LA10_N LOC = V21;
NET FMC_LA11_P LOC = W25;
NET FMC_LA11_N LOC = W26;
NET FMC_LA12_P LOC = W23;
NET FMC_LA12_N LOC = W24;
NET FMC_LA13_P LOC = U22;
NET FMC_LA13_N LOC = V22;
NET FMC_LA14_P LOC = R26;
NET FMC_LA14_N LOC = P26;
NET FMC_LA15_P LOC = T24;
NET FMC_LA15_N LOC = T25;
NET FMC_LA16_P LOC = V23;
NET FMC_LA16_N LOC = V24;
NET FMC_LA17_P LOC = R22;
NET FMC_LA17_N LOC = R23;
NET FMC_LA18_P LOC = P23;
NET FMC_LA18_N LOC = N23;
NET FMC_LA19_P LOC = T22;
NET FMC_LA19_N LOC = T23;
NET FMC_LA20_P LOC = R25;
NET FMC_LA20_N LOC = P25;
NET FMC_LA21_P LOC = M24;
NET FMC_LA21_N LOC = L24;
NET FMC_LA22_P LOC = M25;
NET FMC_LA22_N LOC = L25;
NET FMC_LA23_P LOC = P24;
